Lithium ion in situ temperature change XRD device

Device use

1. 1) The device is suitable for electrochemical in-situ XRD test of positive and negative electrode materials of lithium-ion battery, lithium-sulfur battery, sodium ion battery, water zinc-ion battery and other systems;

2. The device can perform electrochemical in-situ X-ray testing under temperature control

Device parameters;

1. The device includes temperature controller, in situ chamber, heating system (PC software is optional)

2. Device temperature control range; Normal temperature -100℃, temperature control accuracy is less than 0.3℃,

3. The device adopts resistance heating, and the sensor is placed under the sample, which can directly reflect the real temperature change of the sample

4. The main body is made of polymer material, which has good temperature resistance, insulation properties, corrosion resistance and high temperature resistance

5.. The operation is simple, the installation is convenient, the test consistency is good, and the experimental deviation caused by different operation methods is avoided.

6. Easy to operate, small size, easy to disassemble, reusable

7. Device shape 68mm*48mm*26mm

8. The device adopts imported high purity beryllium Windows

9. The device is equipped with a conversion control table and a sample table transition bracket, which can be matched with various types of diffractometer.
