Device parameters; (Temperature customizable

1.The device can be applied to in-situ testing of small-angle scattering of synchrotron radiation X-rays

2. The device includes a temperature controller, an in-situ pool cavity, a heating system, and upper computer software

3. The device adopts PID intelligent control, USB signal transmission, temperature curve data collection, which can be stored and retrieved.

4. Multi-point temperature control correction is available, temperature can be set within limits, and temperature can be set in multiple program segments.

5. Temperature range: Room temperature -200℃, temperature control accuracy ±1℃, heating rate: >80℃/min

6. The device adopts resistance heating, with the sensor placed inside the liquid, which can directly reflect the true temperature changes of the sample

7. The liquid volume is approximately 15mL, and the window diameter is 6mm

9. The device adopts O-ring sealing, which has a good seal and can be filled with reaction gas

10. The device is made of aviation aluminum, with an external dimension of 120mm*70mm*35mm and a net weight of less than 1Kg.

Cooling method of 11 chambers: Circulating water cooling is adopted;

The device is easy to operate and convenient to install.
